ESL Tempest Laser System



A compact, pulsed Nd:YAG laser system delivering maximum performance in a compact, inexpensive platform.



Designed with scientific applications in mind, the Tempest is easy to use and readily adaptable to specific requirements. Its proven resonator design is robust and provides superior beam pointing and energy stability with minimum beam divergence. With four available output beam wavelengths and a wide range of repetition rates (with single-shot, burst and continuous modes), the Tempest provides a complete solution for many applications.

Tags: , ,

Add to quote

Description

More Information

Features

  • Compact flashlamp pumped, Q-switched Nd:YAG laser system
  • Pulse energy per unit volume is highest in the industry — from 100 to 300 mJ at 1064 nm
  • Beam divergence less than 1 mrad at 1064 nm
  • Repetition rates from 10 to 30 Hz
  • Wavelength availability: 1064, 532, 355, and 266nm
  • Flexible operational controls with RS232 and remote control panel
  • Optional optical attenuator makes it easy to control laser energy without changing the beam parameters
  • Compact head configuration minimizes optical bench space requirement and simplifies OEM package design
  • Controllable flashlamp voltage
  • Self-contained cooling system
  • Standard or 19” rack mount power supply

Applications

  • LIBS
  • Micromachining
  • Plasma Physics
  • High energy spectroscopy
  • Scientific research
